Compact and bold
An aluminium and glass body just 86 x 61 x 17mm, with a 3.2-inch screen.
SHANLINGDIGITAL AUDIO PLAYERCustomer reviews (0)
Shanling M1 Plus Hi-Res Digital Audio Player
Compact player, full-size power.
A compact 116g player with an ESS ES9069Q DAC, up to 660mW, Wi-Fi, two-way Bluetooth and Tidal, with 3.5mm and 4.4mm outputs.
Regular price
£209.00
Unit price
Including VAT
Free next day UK delivery
Awaiting stock arrival date — order now to reserve one from the next delivery. Nothing to pay until it arrives.
THE AMP3 DIFFERENCE
Great gear. Even better service.
Order by 12 noon, Monday to Friday, for next day delivery. Destination and stock availability apply.
Not sure it’s your perfect match? Talk to an audio specialist
Shanling M1 Plus Hi-Res Digital Audio Player
A little extra. A better pairing.
Better together.
Hand-picked pairings for this product. Choose one — we'll add them together.
MEET THE M1
Compact player, full-size power.
A compact 116g player with an ESS ES9069Q DAC, up to 660mW, Wi-Fi, two-way Bluetooth and Tidal, with 3.5mm and 4.4mm outputs.
Powerful sound
The ES9069Q DAC and dual SGM8262 amps deliver up to 660mW at 32Ω.
Well connected
Wi-Fi with DLNA and AirPlay, two-way LDAC Bluetooth and Tidal integration.
Read the full description
The Shanling M1 Plus is a compact MTouch music player, the smaller and more affordable sibling of the M5 Ultra, with Shanling’s full feature set and, Shanling says, the highest output in its class. At 86 × 61 × 17mm and 116g it pairs an ESS ES9069Q DAC with two SGM8262 amplifiers for up to 661mW into 32Ω from its 4.4mm balanced output, enough for anything from small earphones to full-size headphones. Wi-Fi with Tidal, DLNA and AirPlay, two-way Bluetooth 5.2, a two-way USB connection, a coaxial output and up to 12.5 hours of playback complete it.
A compact powerhouse
Two SGM8262 amplifiers form a balanced amplifier giving 661mW into 32Ω from the 4.4mm output on high gain (187mW on low gain) and 195mW from the 3.5mm output (47mW on low gain). The aluminium and glass body follows the bold, modern design Shanling introduced with the M5 Ultra, with a 3.2-inch touchscreen that balances easy touch control with a compact size for daily use.
ESS ES9069Q, tuned by experts
The ES9069Q is a hi-fi grade ESS DAC for detailed, accurate and dynamic sound, with a 122dB signal-to-noise ratio and 0.0007% THD+N. It plays PCM up to 32-bit/768kHz and native DSD512, with eight digital filters and adjustable gain.
Signal processing from Shanling’s high-end players
The M1 Plus uses the same advanced signal processing as Shanling’s high-end models: the latest generation of its in-house FPGA technology, with two independent Japanese KDS active crystal oscillators (90.3168MHz and 98.304MHz) for precise timing. Japanese ELNA Silmic II capacitors add to a pleasing, natural tuning.
MTouch: a music-dedicated system
Shanling’s in-house MTouch OS, refined over more than six years, is a simple, fast system focused purely on audio playback, running on the triple-core Ingenic X2000 platform. Music plays from a microSD card of up to 2TB, and the illuminated volume wheel glows green or blue, to match your mood, and red while charging.
Tidal, Wi-Fi and the Eddict Player app
Connect to Wi-Fi and the full Tidal library streams directly on the M1 Plus, developed in co-operation between Shanling and Tidal (online playback only; offline downloads are not available). Wi-Fi also brings DLNA, AirPlay and over-the-air updates, and with SyncLink the Eddict Player app on Android or iOS lets you control playback and browse the whole microSD library from your phone.
Two-way Bluetooth 5.2
Use the M1 Plus as a source for Bluetooth headphones and speakers, or turn it into a Bluetooth DAC and amp for your smartphone on the go, with LDAC, aptX HD, aptX, AAC and SBC in both directions.
USB and coaxial
The two-way USB-C connection makes the M1 Plus a USB DAC for a computer or phone (up to 384kHz/32-bit and DSD256), or sends a digital signal out to an external DAC. The 3.5mm socket doubles as a coaxial S/PDIF output, up to 192kHz/24-bit.
Up to 12.5 hours
The 2,100mAh battery and advanced power management give up to 12.5 hours from the 3.5mm output, 10 hours balanced, 24 hours as a Bluetooth transmitter and up to 270 hours on standby (Shanling’s tests; real use may differ), and it works with QC and PD chargers. The M1 Plus is certified Hi-Res Audio and Hi-Res Audio Wireless by the Japan Audio Society.
| DAC and amp | ESS ES9069Q · 2 × SGM8262 · FPGA with 2 KDS oscillators · Ingenic X2000 · MTouch OS |
|---|---|
| 4.4mm balanced | 661mW @ 32Ω (4.6Vrms, high gain) · 187mW (low) · SNR 122dB · THD+N 0.0007% · separation 100dB · 1.2Ω |
| 3.5mm | 195mW @ 32Ω (2.5Vrms, high gain) · 47mW (low) · SNR 122dB · THD+N 0.0007% · separation 74dB · 0.6Ω · coaxial out (192kHz/24-bit) |
| Frequency response | 20Hz–40kHz (−0.5dB) |
| Formats | PCM to 768kHz/32-bit · DSD512 (ISO, DSF, DFF; DST not supported) · DXD, APE, FLAC, WAV, AIFF, DTS, MP3, WMA, AAC, OGG, ALAC, MP2, M4A, AC3, Opus · M3U, M3U8 |
| Wireless | Wi-Fi 2.4/5GHz (Tidal, DLNA, AirPlay, OTA) · Bluetooth 5.2 two-way: LDAC, aptX HD, aptX, AAC, SBC |
| USB | Two-way USB-C · USB DAC 384kHz/32-bit, DSD256 |
| Screen and storage | 3.2-inch 320 × 480 touchscreen · microSD up to 2TB |
| Battery | 2,100mAh · 12.5h (3.5mm) · 10h (4.4mm) · 24h (Bluetooth transmit) · 270h standby |
| Size and weight | 86 × 61 × 17mm · 116g |
Good to know
- There is no built-in storage: add a microSD card (up to 2TB).
- Tidal on the M1 Plus is for online playback only.
- In the box: M1 Plus, USB-A to USB-C cable, screen protector, manual and warranty card. Black or silver.
In the box
- Shanling M1 Plus
- USB-A to USB-C cable
- Screen protector
- Manual and warranty card
Downloads
THE FINER DETAILS
Built for
better listening.
Know what you’re choosing.
Find the right fit for your setup.
- DAC
- ESS ES9069Q
- Operating system
- MTouch (Ingenic X2000)
- Headphone outputs
- 3.5mm single-ended · 4.4mm balanced
- Output power
- 661mW @ 32Ω (4.4mm, high gain) · 195mW @ 32Ω (3.5mm, high gain)
- Frequency response
- 20Hz–40kHz (−0.5dB)
- Hi-res support
- PCM 768kHz/32-bit · DSD512 (USB DAC: 384kHz/32-bit, DSD256)
- Battery
- 2,100mAh · up to 12.5 hours (3.5mm), 10 hours (4.4mm), 24 hours (Bluetooth transmit) · up to 270 hours standby · QC and PD chargers
- Storage
- microSD up to 2TB
- Screen
- 3.2-inch 320 × 480 touchscreen
- Bluetooth
- 5.2 two-way (transmit and receive)
- Bluetooth codecs
- LDAC, aptX HD, aptX, AAC, SBC
- Wi-Fi & streaming
- 2.4/5GHz · DLNA, AirPlay
- Gain modes
- Low / high
- Remote control
- Eddict Player app (iOS/Android)
- Signal-to-noise ratio
- 122dB
- Distortion (THD+N)
- 0.0007%
- Output impedance
- 0.6Ω (3.5mm) · 1.2Ω (4.4mm)
- Crosstalk
- 100dB (4.4mm) · 74dB (3.5mm), @ 32Ω
- Size (H × W × D)
- 86 × 61 × 17mm
- Weight
- 116g
- Amplification
- 2 × SGM8262
- Digital outputs
- Coaxial S/PDIF via the 3.5mm jack (PCM 192kHz/24-bit)
- Finishes
- BLACK / SILVER
Specifications are based on manufacturer information and may change. Battery life varies with use and settings.
